Commercial Gas Stack Dryer, Coin-Drop Equipped - CSP2941HQ

This product has been discontinued by the manufacture and is no longer available.

Commercial Gas Stack Dryer, Coin-Drop Equipped

Model: CSP2941HQ

Commercial Gas Stack Dryer, Coin-Drop Equipped CSP2941HQCommercial Gas Stack Dryer, Coin-Drop Equipped CSP2941HQCommercial Gas Stack Dryer, Coin-Drop Equipped CSP2941HQCommercial Gas Stack Dryer, Coin-Drop Equipped CSP2941HQCommercial Gas Stack Dryer, Coin-Drop Equipped CSP2941HQ
Commercial Gas Stack Dryer, Coin-Drop Equipped CSP2941HQ
Commercial Gas Stack Dryer, Coin-Drop Equipped CSP2941HQ
Commercial Gas Stack Dryer, Coin-Drop Equipped CSP2941HQ
Commercial Gas Stack Dryer, Coin-Drop Equipped CSP2941HQ
Commercial Gas Stack Dryer, Coin-Drop Equipped CSP2941HQ

Color : White

Commercial Gas Stack Dryer, Coin-Drop Equipped CSP2941HQ
White

Type : Gas

Key Features

  • Space Saving Design

  • Balanced Airflow System

  • Front Service Accessibility

  • SINGLE OPERATING THERMOSTAT

  • wide-opening, side-swing door

  • easy-to-use push button controls

  • Factory Installed Coin Drop and Coin Box

  • Ease of Use

Read More

Available from Slyman Bros, serving customers throughout Missouri.

Features
Specifications

Features

Space Saving Design

Maximizing floor space can help get additional washers and dryers on the floor to increase facility productivity. At 7.4 cu. ft. per dryer, this stack option provides double the drying capability while taking up the room of only a single unit.

Balanced Airflow System

Front Service Accessibility

SINGLE OPERATING THERMOSTAT

wide-opening, side-swing door

easy-to-use push button controls

Factory Installed Coin Drop and Coin Box

A robust coin drop and coin box come installed from the factory. Coin drop allows flexibilty in pricing your machines for your market.

Ease of Use

Comfortable loading and simple cycle navigation are conveniences that make a difference to any user. With a wide-opening, side-swing door and easy-to-use push button controls, our stack dryer makes getting laundry done an uncomplicated task.

Super-Capacity

The 7.4-cu.-ft. super-capacity means loads from small to extra-large can be dried efficiently and effectively.

Four-Roller Suspension

The commercial-quality four-roller suspension delivers daily, quality drying.

1/3-HP motor with metal pulley

Removable, door-mounted lint screen

2-Year Limited Parts Warranty/90-Day Labor

Visit whirlpoolcommerciallaundry.com for complete warranty details.

3 Cycles: Heavy-Duty (High Heat), Normal (Medium Heat), and Delicates (Low Heat)

Specifications

Warranty

Parts90 Day
Labor90 Day

Details

Dryer Capacity (cu. ft.)7.4
Drum MaterialPowder Coat
Heating Burner (BTU)22000

Cycles

Number of Dryer Cycles3

Certifications

Prop 65Standard

Dryer Features

Cycle Time RemainingYes
Eco MonitorNo
Lint Filter IndicatorYes
Moisture SensorNo

Dryer Installation Considerations

Maximum Vent Length (ft.)64
Venting DirectionLeft, Right, Rear

Dryer Temperature Settings

Dryer Temperature SelectionsHigh, Low, Medium

Electrical

Amps15
Volts120

Exterior

Reversible DoorYes

Specifications

Card Reader ReadyNo
Coin Drop ReadyYes
Full Width ConsoleYes
Meter CaseYes
Number of Optic Sensors2
Service Mode ActivationYes
Self-DiagnosticsYes

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement34.78 ft³
Dimensional Weight432.34 lbs.
Total of Cubes34.78 ft³
Total of Dimensional Weight432.34 lbs.

Dimensions & Weight

Width27 in.
Height76.75 in.
Length29 in.
Weight295 lbs.
Carton Depth33 7/16
Carton Height79 1/16
Carton Width28 3/4
Gross Weight295
Net Weight273.0
Depth With Door Open 90 Degree(IN,inches)52.7500
Net Weight(LB,pounds)273
Carton Depth(IN,inches)33.4375
Carton Height(IN,inches)79.0625
Carton Width(IN,inches)28.7500
Door Opening Height(IN,inches)12.00
Door Opening Width(IN,inches)20.25
Gross Weight(LB,pounds)295

Number of Boxes, Shipping Dimensions, & Shipping Weight

Number of Boxes1
Shipping Width28.75 in.
Shipping Height79.06 in.
Shipping Length34 in.
Shipping Weight335 lbs.
Total of Shipping Weight335 lbs.
SourceCalculation

Other

Capacity (IEC) (Cu Ft)7.4
Capacity(FT3,cubic feet)7.40
