Name: Flaker Icemaker, Water-cooled
Brand: Hoshizaki
SKU: F1501MWJ
Availability: BackOrder

Flaker Icemaker, Water-cooled

Model : #F1501MWJ

Flaker Icemaker, Water-cooled

Model: F1501MWJ

+3more

Flaker Icemaker, Water-cooled

Model: F1501MWJ

Color : Stainless Steel

Key Features

Up to 1624 lbs of ice produced per 24 hours
Mount 2 units side-by-side for 2x the ice production
Produces flaked ice
Durable stainless steel exterior
Compatible bins & dispensers, sold separately: B-250, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650, B-1300, B-1500, B-1650
2 second rinse every hour to remove sediment
Infrared bin control for easy cleaning and reliability
R-404A refrigerant (1 lbs. 4.5 oz. / 580 g)

Description

The F-1501MWJ is capable of producing approximately 1624 lbs of flaked ice per day. Flaked ice is perfect for salad bars, seafood counters, and other food displays that require long lasting sanitary ice. This Water-cooled, Modular icemaker features the Advanced CleanCycle24™ design plus a greaseless bearing auger construction making it simple to maintain. The F-1501MWJ requires a Single phase, 208-230v/60/1, 4 wire, including ground. Must be hardwired at site, no cord/plug included electrical connection that is hard-wired at the installation site. Compatible bins & dispensers, sold separately: B-250, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650, B-1300, B-1500, B-1650. Please consult the Specification Sheet for additional details.

Documents

Parts Manual

View | Download

PDF, 7.11 MB

Warranty Statement

View | Download

PDF, 1022.59 KB

Specification Sheet

View | Download

PDF, 1.86 MB

Instruction Manual

View | Download

PDF, 6.18 MB

Service Manual

View | Download

PDF, 4.36 MB

Available from Slyman Bros, serving customers throughout Missouri.

Features

Specifications

Features

Up to 1624 lbs of ice produced per 24 hours

Mount 2 units side-by-side for 2x the ice production

Produces flaked ice

Durable stainless steel exterior

Compatible bins & dispensers, sold separately: B-250, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650, B-1300, B-1500, B-1650

2 second rinse every hour to remove sediment

Infrared bin control for easy cleaning and reliability

R-404A refrigerant (1 lbs. 4.5 oz. / 580 g)

15.4 amps (20 Amp Max fuse)

3.2 kwh/100 lbs.@ 90/70

Three Years: Parts & Labor warranty on entire machine. (Serial numbers VxxxxxJ and after).

Clean ice and easy maintenance lead to longer unit life span

Single phase, 208-230v/60/1, 4 wire, including ground. Must be hardwired at site, no cord/plug included

Five Years: Parts warranty on Compressor, air-cooled condenser coil.

Advanced CleanCycle24™ design

Heat Rejection:12900 BTU/hr

Specifications

Product Details

Utility Consumption	3.2 kWh per 100 lbs @ 90/70, 12 gal of Potable Water per 100 lbs @ 90/70
Electrical Specs	Single phase, 208-230v/60/1, 4 wire, including ground. Must be hardwired at site, no cord/plug included, Amperage: 15.4, Max Fuse/HACR Breaker: 20 A
Operating Limits	Ambient Temp Range: 45 – 100°F, Water Temp Range: 45 – 90°F, Water Pressure: 10 – 113psig, Voltage Range: 187 – 253V, Heat Rejection: 12900 BTU/hr, Refrigerant Charge: R-404A, (1 lbs. 4.5 oz.
Plumbing Specs	1/2″ FPT Inlet, Minimum 1/4″ Nominal ID Copper Water Tubing or Equivalent, 3/8″ FPT Outlet, Minimum 1/4″ Nominal ID Hard Pipe or Equivalent, Minimum 1/4″ Nominal ID Copper Water Tubing or Equ
Shipping Weight	350

Dimensions & Weight
