Name: Cubelet Icemaker, Water-cooled
Brand: Hoshizaki
SKU: F1501MWJC
Availability: BackOrder

Cubelet Icemaker, Water-cooled

Model : #F1501MWJC

Cubelet Icemaker, Water-cooled

Model: F1501MWJC

Cubelet Icemaker, Water-cooled

Model: F1501MWJC

Color : Stainless Steel

Key Features

Mount 2 units side-by-side for 2x the ice production
Up to 1376 lbs of ice produced per 24 hours
Durable stainless steel exterior
Compatible bins & dispensers, sold separately: B-250, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650, B-1300, B-1500, B-1650
2 second rinse every hour to remove sediment
Produces medium cubelet nugget-style ice
Infrared bin control for easy cleaning and reliability
R-404A refrigerant (1 lbs. 4.5 oz. / 580 g)

Description

The F-1501MWJ-C is capable of producing approximately 1376 lbs of cubelet (nugget-style) ice per day. Cubelet ice is the most popular ice for drinks – as it cools the beverage quickly and absorbs the flavor making an easy-to-chew treat. This Water-cooled, Modular icemaker features the Advanced CleanCycle24™ design plus a greaseless bearing auger construction making it simple to maintain. The F-1501MWJ-C requires a Single phase, 208-230v/60/1, 4 wire, including ground. Must be hardwired at site, no cord/plug included electrical connection that is hard-wired at the installation site. Compatible bins & dispensers, sold separately: B-250, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650, B-1300, B-1500, B-1650. Please consult the Specification Sheet for additional details.

Documents

Warranty Statement

View | Download

PDF, 1022.59 KB

Parts Manual

View | Download

PDF, 7.11 MB

Specification Sheet

View | Download

PDF, 1.86 MB

Instruction Manual

View | Download

PDF, 6.18 MB

Service Manual

View | Download

PDF, 4.36 MB

Available from Slyman Bros, serving customers throughout Missouri.

Features

Specifications

Features

Mount 2 units side-by-side for 2x the ice production

Up to 1376 lbs of ice produced per 24 hours

Durable stainless steel exterior

Compatible bins & dispensers, sold separately: B-250, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650, B-1300, B-1500, B-1650

2 second rinse every hour to remove sediment

Produces medium cubelet nugget-style ice

Infrared bin control for easy cleaning and reliability

R-404A refrigerant (1 lbs. 4.5 oz. / 580 g)

15.4 amps (20 Amp Max fuse)

3.76 kwh/100 lbs.@ 90/70

Single phase, 208-230v/60/1, 4 wire, including ground. Must be hardwired at site, no cord/plug included

Clean ice and easy maintenance lead to longer unit life span

Three Years: Parts & Labor warranty on entire machine. (Serial numbers VxxxxxJ and after).

Five Years: Parts warranty on Compressor, air-cooled condenser coil.

Advanced CleanCycle24™ design

Heat Rejection:12800 BTU/hr

Specifications

Product Details

Utility Consumption	3.76 kWh per 100 lbs @ 90/70, 12 gal of Potable Water per 100 lbs @ 90/70
Electrical Specs	Single phase, 208-230v/60/1, 4 wire, including ground. Must be hardwired at site, no cord/plug included, Amperage: 15.4, Max Fuse/HACR Breaker: 20 A
Operating Limits	Ambient Temp Range: 45 – 100°F, Water Temp Range: 45 – 90°F, Water Pressure: 10 – 113psig, Voltage Range: 187 – 253V, Heat Rejection: 12800 BTU/hr, Refrigerant Charge: R-404A, (1 lbs. 4.5 oz.
Plumbing Specs	1/2″ FPT Inlet, Minimum 1/4″ Nominal ID Copper Water Tubing or Equivalent, 3/8″ FPT Outlet, Minimum 1/4″ Nominal ID Hard Pipe or Equivalent, Minimum 1/4″ Nominal ID Copper Water Tubing or Equ
Shipping Weight	330

Dimensions & Weight
