Name: Flaker Icemaker, Low Side Remote-cooled
Brand: Hoshizaki
SKU: F2001MLJ
Availability: BackOrder

Flaker Icemaker, Low Side Remote-cooled

Model : #F2001MLJ

Flaker Icemaker, Low Side Remote-cooled

Model: F2001MLJ

Flaker Icemaker, Low Side Remote-cooled

Model: F2001MLJ

Color : Stainless Steel

Key Features

Up to 2280 lbs of ice produced per 24 hours
Mount 2 units side-by-side for 2x the ice production
Durable stainless steel exterior
Compatible bins & dispensers, sold separately: B-250, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650, B-1300, B-1500, B-1650
2 second rinse every hour to remove sediment
Produces flaked ice
Can be used with refrigerant R-404A, R407A, R407F
Voltage range: 104-127V

Description

The F-2001MLJ is capable of producing approximately 2280 lbs of flaked ice per day. Flaked ice is perfect for salad bars, seafood counters, and other food displays that require long lasting sanitary ice. This Low Side Remote, Modular, Low-Side Series icemaker features the Advanced CleanCycle24™ design plus a greaseless bearing auger construction making it simple to maintain. The F-2001MLJ requires a Single phase, 115v/60/1 electrical connection that is hard-wired at the installation site. Compatible bins & dispensers, sold separately: B-250, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650, B-1300, B-1500, B-1650. Please consult the Specification Sheet for additional details.

Documents

Specification Sheet

View | Download

PDF, 928.55 KB

Parts Manual

View | Download

PDF, 8.43 MB

Warranty Statement

View | Download

PDF, 1022.59 KB

Instruction Manual

View | Download

PDF, 6.18 MB

Service Manual

View | Download

PDF, 4.36 MB

Available from Slyman Bros, serving customers throughout Missouri.

Features

Specifications

Features

Up to 2280 lbs of ice produced per 24 hours

Mount 2 units side-by-side for 2x the ice production

Durable stainless steel exterior

Compatible bins & dispensers, sold separately: B-250, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650, B-1300, B-1500, B-1650

2 second rinse every hour to remove sediment

Produces flaked ice

Can be used with refrigerant R-404A, R407A, R407F

Voltage range: 104-127V

6.1 amps (15 Amp Max fuse)

0.6 kwh/100 lbs.@ 90/70

Clean ice and easy maintenance lead to longer unit life span

Advanced CleanCycle24™ design

Heat Rejection: BTU/hr

Single phase, 115v/60/1

Three Years: Parts & Labor warranty on entire machine.

Specifications

Product Details

Electrical Specs	Single phase, 115v/60/1 , Amperage: 6.1, Max Fuse/HACR Breaker: 15 A
Utility Consumption	0.6 kWh per 100 lbs @ 90/70, 12 gal of Potable Water per 100 lbs @ 90/70
Operating Limits	Ambient Temp Range: 45 – 100°F, Water Temp Range: 45 – 90°F, Water Pressure: 10 – 113psig, Voltage Range: 104-127V, Heat Rejection: BTU/hr, Refrigerant Charge: R-404A, R407A, R407F, (Nitrogen
Plumbing Specs	1/2″ FPT Inlet, Minimum 1/4″ Nominal ID Copper Water Tubing or Equivalent, 3/4″ FPT Outlet, Minimum 3/4″ Nominal ID Hard Pipe or Equivalent
Shipping Weight	250
