Flaker Icemaker, Air-cooled, Built in Storage Bin - F300BAJ

Flaker Icemaker, Air-cooled, Built in Storage Bin

Model: F300BAJ

Flaker Icemaker, Air-cooled, Built in Storage Bin F300BAJFlaker Icemaker, Air-cooled, Built in Storage Bin F300BAJFlaker Icemaker, Air-cooled, Built in Storage Bin F300BAJFlaker Icemaker, Air-cooled, Built in Storage Bin F300BAJFlaker Icemaker, Air-cooled, Built in Storage Bin F300BAJFlaker Icemaker, Air-cooled, Built in Storage Bin F300BAJ
Flaker Icemaker, Air-cooled, Built in Storage Bin F300BAJ
Flaker Icemaker, Air-cooled, Built in Storage Bin F300BAJ
Flaker Icemaker, Air-cooled, Built in Storage Bin F300BAJ
Flaker Icemaker, Air-cooled, Built in Storage Bin F300BAJ
Flaker Icemaker, Air-cooled, Built in Storage Bin F300BAJ
+1more

Color : Stainless Steel

Flaker Icemaker, Air-cooled, Built in Storage Bin F300BAJ
Stainless Steel

Key Features

  • Up to 353 lbs of ice produced per 24 hours

  • Up to 100 lbs of built-in storage capacity (3.7ft3)

  • Produces flaked ice

  • Durable stainless steel exterior

  • Front in, front out airflow

  • Gear motor protected from overload

  • Automatic system flush when bin control is activated

  • Designed for long life dependability

Read More

Description

The F-300BAJ is capable of producing approximately 353 lbs of flaked ice per day. Flaked ice is perfect for salad bars, seafood counters, and other food displays that require long lasting sanitary ice. This Air-cooled, Self Contained, Built in Storage Bin icemaker stores up to 100 lbs of ice*. It features an Automatic system flush when bin control is activated plus a greaseless bearing auger construction making it simple to maintain. The F-300BAJ requires a Single phase, 115v/60/1, 8 ft cord with NEMA 5-15 plug electrical connection. Front in, front out airflow. Please consult the Specification Sheet for additional details.*Rated in accordance with AHRI Standard 820(I-P). Capacity based on 100% of total volume x 30 lb/ft3 average density of ice.
Read More

Available from Slyman Bros, serving customers throughout Missouri.

Features
Specifications

Features

Up to 353 lbs of ice produced per 24 hours

Up to 100 lbs of built-in storage capacity (3.7ft3)

Produces flaked ice

Durable stainless steel exterior

Front in, front out airflow

Gear motor protected from overload

Automatic system flush when bin control is activated

Designed for long life dependability

R-404A refrigerant (9.2 oz. / 260 g)

7.8 amps (15 Amp Max fuse)

6.14 kwh/100 lbs.@ 90/70

Single phase, 115v/60/1, 8 ft cord with NEMA 5-15 plug

Three Years: Parts & Labor warranty on entire machine.

Five Years: Parts warranty on Compressor, air-cooled condenser coil.

Clean ice and easy maintenance lead to longer unit life span

Heat Rejection:2300 BTU/hr

Specifications

Product Details

Utility Consumption6.14 kWh per 100 lbs @ 90/70, 12 gal of Potable Water per 100 lbs @ 90/70
Electrical SpecsSingle phase, 115v/60/1 8 ft cord with NEMA 5-15 Plug, Amperage: 7.8, Max Fuse/HACR Breaker: 15 A
Operating LimitsAmbient Temp Range: 45 – 100°F, Water Temp Range: 45 – 90°F, Water Pressure: 10 – 113psig, Voltage Range: 104 – 127V, Heat Rejection: 2300 BTU/hr, Refrigerant Charge: R-404A, (9.2 oz. / 260 g
Plumbing Specs1/2″ FPT Inlet, Minimum 1/4″ Nominal ID Copper Water Tubing or Equivalent, 3/4″ FPT Outlet, Minimum 3/4″ Nominal ID Hard Pipe or Equivalent
Shipping Weight200

Dimensions & Weight

Width-
Height-
Length-
Weight200 lbs.
Width36 in.
Depth24.25 in.
Height39.25 in.

Number of Boxes, Shipping Dimensions, & Shipping Weight

Number of Boxes1
Shipping Width-
Shipping Height-
Shipping Length-
Shipping Weight240 lbs.
Total of Shipping Weight240 lbs.
SourceCalculation

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement-
Dimensional Weight-
Total of Cubes-
Total of Dimensional Weight-

Warranty

Parts3 Years
Labor3 Years
