Flaker Icemaker, Air-cooled, Built in Storage Bin - F500BAJ

Flaker Icemaker, Air-cooled, Built in Storage Bin

Model: F500BAJ

F-500BAJ, Flaker Icemaker, Air-cooled, Built in Storage BinTitle F500BAJF-500BAJ, Flaker Icemaker, Air-cooled, Built in Storage BinTitle F500BAJF-500BAJ, Flaker Icemaker, Air-cooled, Built in Storage BinTitle F500BAJF-500BAJ, Flaker Icemaker, Air-cooled, Built in Storage BinTitle F500BAJF-500BAJ, Flaker Icemaker, Air-cooled, Built in Storage BinTitle F500BAJF-500BAJ, Flaker Icemaker, Air-cooled, Built in Storage BinTitle F500BAJ
F-500BAJ, Flaker Icemaker, Air-cooled, Built in Storage BinTitle F500BAJ
F-500BAJ, Flaker Icemaker, Air-cooled, Built in Storage BinTitle F500BAJ
F-500BAJ, Flaker Icemaker, Air-cooled, Built in Storage BinTitle F500BAJ
F-500BAJ, Flaker Icemaker, Air-cooled, Built in Storage BinTitle F500BAJ
F-500BAJ, Flaker Icemaker, Air-cooled, Built in Storage BinTitle F500BAJ
+1more

Color : Stainless Steel

product image
Stainless Steel

Key Features

  • Up to 536 lbs of ice produced per 24 hours

  • Up to 170 lbs of built-in storage capacity (5.7ft3)

  • Durable stainless steel exterior

  • Front in, front out airflow

  • Automatic system flush when bin control is activated

  • Produces flaked ice

  • Designed for long life dependability

  • R-404A refrigerant (1 lbs. 0.6 oz. / 470 g)

Read More

Description

The F-500BAJ is capable of producing approximately 536 lbs of flaked ice per day. Flaked ice is perfect for salad bars, seafood counters, and other food displays that require long lasting sanitary ice. This Air-cooled, Self Contained, Built in Storage Bin icemaker stores up to 170 lbs of ice*. It features an Automatic system flush when bin control is activated plus a greaseless bearing auger construction making it simple to maintain. The F-500BAJ requires a Single phase, 115v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included electrical connection. Front in, front out airflow. Please consult the Specification Sheet for additional details.*Rated in accordance with AHRI Standard 820(I-P). Capacity based on 100% of total volume x 30 lb/ft3 average density of ice.
Read More

Available from Slyman Bros, serving customers throughout Missouri.

Features
Specifications

Features

Up to 536 lbs of ice produced per 24 hours

Up to 170 lbs of built-in storage capacity (5.7ft3)

Durable stainless steel exterior

Front in, front out airflow

Automatic system flush when bin control is activated

Produces flaked ice

Designed for long life dependability

R-404A refrigerant (1 lbs. 0.6 oz. / 470 g)

Gear motor protected from overload

5.05 kwh/100 lbs.@ 90/70

Single phase, 115v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included

Clean ice and easy maintenance lead to longer unit life span

Three Years: Parts & Labor warranty on entire machine.

13.8 amps (20 Amp Max fuse)

Five Years: Parts warranty on Compressor, air-cooled condenser coil.

Heat Rejection:2500 BTU/hr

Specifications

Product Details

Electrical SpecsSingle phase, 115v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included, Amperage: 13.8, Max Fuse/HACR Breaker: 20 A
Utility Consumption5.05 kWh per 100 lbs @ 90/70, 12 gal of Potable Water per 100 lbs @ 90/70
Operating LimitsAmbient Temp Range: 45 – 100°F, Water Temp Range: 45 – 90°F, Water Pressure: 10 – 113psig, Voltage Range: 104 – 127V, Heat Rejection: 2500 BTU/hr, Refrigerant Charge: R-404A, (1 lbs. 0.6 oz.
Plumbing Specs1/2″ FPT Inlet, Minimum 1/4″ Nominal ID Copper Water Tubing or Equivalent, 3/4″ FPT Outlet, Minimum 3/4″ Nominal ID Hard Pipe or Equivalent
Shipping Weight265

Dimensions & Weight

Width-
Height-
Length-
Weight265 lbs.
Width38.125 in.
Depth29.125 in.
Height42 in.

Number of Boxes, Shipping Dimensions, & Shipping Weight

Number of Boxes1
Shipping Width-
Shipping Height-
Shipping Length-
Shipping Weight305 lbs.
Total of Shipping Weight305 lbs.
SourceCalculation

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement-
Dimensional Weight-
Total of Cubes-
Total of Dimensional Weight-

Warranty

Parts3 Years
Labor3 Years
