Name: Cubelet Icemaker, Water-cooled
Brand: Hoshizaki
SKU: F801MWJC
Availability: BackOrder

Cubelet Icemaker, Water-cooled

Model : #F801MWJC

Cubelet Icemaker, Water-cooled

Model: F801MWJC

Cubelet Icemaker, Water-cooled

Model: F801MWJC

Color : Stainless Steel

Key Features

Up to 632 lbs of ice produced per 24 hours
Mount 2 units side-by-side for 2x the ice production
Produces small cubelet nugget-style ice
Durable stainless steel exterior
Compatible bins & dispensers, sold separately: B-250, B-300, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650, B-1150, B-1300, B-1500, B-1650
2 second rinse every hour to remove sediment for cleaner ice
Infrared bin control for easy cleaning and reliability
R-404A refrigerant (1 lbs. 12 oz. / 790 g)

Description

The F-801MWJ-C is capable of producing approximately 632 lbs of cubelet (nugget-style) ice per day. Cubelet ice is the most popular ice for drinks – as it cools the beverage quickly and absorbs the flavor making an easy-to-chew treat. This Water-cooled, Slim Line Modular icemaker features the Advanced CleanCycle24™ design plus a greaseless bearing auger construction making it simple to maintain. The F-801MWJ-C requires a Single phase, 115v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included electrical connection that is hard-wired at the installation site. Compatible bins & dispensers, sold separately: B-250, B-300, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650, B-1150, B-1300, B-1500, B-1650. Please consult the Specification Sheet for additional details.

Documents

Specification Sheet

View | Download

PDF, 1.21 MB

Parts Manual

View | Download

PDF, 4.67 MB

Warranty Statement

View | Download

PDF, 1022.59 KB

Instruction Manual

View | Download

PDF, 6.71 MB

Service Manual

View | Download

PDF, 6.24 MB

Available from Slyman Bros, serving customers throughout Missouri.

Features

Specifications

Features

Up to 632 lbs of ice produced per 24 hours

Mount 2 units side-by-side for 2x the ice production

Produces small cubelet nugget-style ice

Durable stainless steel exterior

Compatible bins & dispensers, sold separately: B-250, B-300, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650, B-1150, B-1300, B-1500, B-1650

2 second rinse every hour to remove sediment for cleaner ice

Infrared bin control for easy cleaning and reliability

R-404A refrigerant (1 lbs. 12 oz. / 790 g)

11.5 amps (15 Amp Max fuse)

4.13 kwh/100 lbs.@ 90/70

Single phase, 115v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included

Three Years: Parts & Labor warranty on entire machine.

Five Years: Parts warranty on Compressor, air-cooled condenser coil.

Advanced CleanCycle24™ design

Heat Rejection: BTU/hr

Specifications

Product Details

Electrical Specs	Single phase, 115v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included, Amperage: 11.5, Max Fuse/HACR Breaker: 15 A
Utility Consumption	4.13 kWh per 100 lbs @ 90/70, 12 gal of Potable Water per 100 lbs @ 90/70
Operating Limits	Ambient Temp Range: 45 – 100°F, Water Temp Range: 45 – 90°F, Water Pressure: 10 – 113psig, Voltage Range: 104 – 127V, Heat Rejection: BTU/hr, Refrigerant Charge: R-404A, (10.6 oz. / 300 g)
Plumbing Specs	1/2″ FPT Inlet, Minimum 1/4″ Nominal ID Copper Water Tubing or Equivalent, 3/8″ FPT Outlet, Minimum 1/4″ Nominal ID Hard Pipe or Equivalent, Minimum 1/4″ Nominal ID Copper Water Tubing or Equ
Shipping Weight	200
