Name: Crescent® Cuber Icemaker, Air-cooled
Brand: Hoshizaki
SKU: KM1100MAJ
Availability: BackOrder

Crescent® Cuber Icemaker, Air-cooled

Model : #KM1100MAJ

Crescent® Cuber Icemaker, Air-cooled

Model: KM1100MAJ

Crescent® Cuber Icemaker, Air-cooled

Model: KM1100MAJ

Color : Stainless Steel

Key Features

Up to 1087 lbs of ice produced per 24 hours
Durable stainless steel exterior
Compatible bins & dispensers, sold separately: B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650
Mount 2 units side-by-side for 2x the ice production
Produces crescent shaped ice cubes
R-404A refrigerant (3 lbs. 1.4 oz. / 1400 g)
12.5 amps (20 Amp Max fuse)
4.9 kwh/100 lbs.@ 90/70

Description

The KM-1100MAJ is capable of producing approximately 1087 lbs of crescent cubed ice. The energy efficient KMEdge™ design incorporates a dual-sided stainless steel evaporator. Its ice on beverage design makes it ideal for use in busy self-serve areas, fast food restaurants, employee break rooms and more. This Air-cooled, Modular icemaker features a CycleSaver™ design and includes the EverCheck™ alert system making the unit energy efficient and simple to maintain. The KM-1100MAJ requires a Single phase, 208-230v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included electrical connection that is hard-wired at the installation site. Compatible bins & dispensers, sold separately: B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650. Please consult the Specification Sheet for additional details.

Documents

Instruction Manual

View | Download

PDF, 3.66 MB

Parts Manual

View | Download

PDF, 5.13 MB

Service Manual

View | Download

PDF, 3.98 MB

Warranty Statement

View | Download

PDF, 999.31 KB

Specification Sheet

View | Download

PDF, 1.60 MB

Spec

View | Download

PDF, 1.50 MB

Available from Slyman Bros, serving customers throughout Missouri.

Features

Specifications

Features

Up to 1087 lbs of ice produced per 24 hours

Durable stainless steel exterior

Compatible bins & dispensers, sold separately: B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650

Mount 2 units side-by-side for 2x the ice production

Produces crescent shaped ice cubes

R-404A refrigerant (3 lbs. 1.4 oz. / 1400 g)

12.5 amps (20 Amp Max fuse)

4.9 kwh/100 lbs.@ 90/70

Single phase, 208-230v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included

Clean ice and easy maintenance lead to longer unit life span

EverCheck™ alert system

CycleSaver™ design

Integrated ultrasonic bin control

Simple, one-hour cleaning and assisted cleaning process with CleanAssist

Heat Rejection: 15700 BTU/hr

Three Years: Parts & Labor warranty on entire machine

Five Years: Parts & Labor warranty on evaporator

Specifications

Product Details

Electrical Specs	Single phase, 208-230v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included, Amperage: 12.5, Max Fuse/HACR Breaker: 20 A
Utility Consumption	4.9 kWh per 100 lbs @ 90/70, 19 gal of Potable Water per 100 lbs @ 90/70
Operating Limits	Ambient Temp Range: 45 – 100°F, Water Temp Range: 45 – 90°F, Water Pressure: 10 – 113psig, Voltage Range: 187 – 253V, Heat Rejection: 15700 BTU/hr, Refrigerant Charge: R-404A, (3 lbs. 1.4 oz.
Plumbing Specs	1/2″ FPT Inlet, Minimum 3/8″ Nominal ID Copper Water Tubing or Equivalent, 3/4″ FPT Outlet, Minimum 3/4″ Nominal ID Hard Pipe or Equivalent
Shipping Weight	295
