Name: Crescent® Cuber Icemaker, Water-cooled
Brand: Hoshizaki
SKU: KM1100MWJ
Availability: BackOrder

Crescent® Cuber Icemaker, Water-cooled

Model : #KM1100MWJ

Crescent® Cuber Icemaker, Water-cooled

Model: KM1100MWJ

Crescent® Cuber Icemaker, Water-cooled

Model: KM1100MWJ

Color : Stainless Steel

Key Features

Up to 1073 lbs of ice produced per 24 hours
Mount 2 units side-by-side for 2x the ice production
Produces crescent shaped ice cubes
Compatible bins & dispensers, sold separately: B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650
Durable stainless steel exterior
R-404A refrigerant (1 lbs. 10.5 oz. / 751 g)
4 kwh/100 lbs.@ 90/70
Single phase, 208-230v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included

Description

The KM-1100MWJ is capable of producing approximately 1073 lbs of crescent cubed ice. The energy efficient KMEdge™ design incorporates a dual-sided stainless steel evaporator. Its ice on beverage design makes it ideal for use in busy self-serve areas, fast food restaurants, employee break rooms and more. This Water-cooled, Modular icemaker features a CycleSaver™ design and includes the EverCheck™ alert system making the unit energy efficient and simple to maintain. The KM-1100MWJ requires a Single phase, 208-230v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included electrical connection that is hard-wired at the installation site. Compatible bins & dispensers, sold separately: B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650. Please consult the Specification Sheet for additional details.

Documents

Instruction Manual

View | Download

PDF, 3.66 MB

Service Manual

View | Download

PDF, 3.98 MB

Warranty Statement

View | Download

PDF, 999.31 KB

Parts Manual

View | Download

PDF, 5.13 MB

Specification Sheet

View | Download

PDF, 1.60 MB

Spec

View | Download

PDF, 1.50 MB

Available from Slyman Bros, serving customers throughout Missouri.

Features

Specifications

Features

Up to 1073 lbs of ice produced per 24 hours

Mount 2 units side-by-side for 2x the ice production

Produces crescent shaped ice cubes

Compatible bins & dispensers, sold separately: B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650

Durable stainless steel exterior

R-404A refrigerant (1 lbs. 10.5 oz. / 751 g)

4 kwh/100 lbs.@ 90/70

Single phase, 208-230v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included

Clean ice and easy maintenance lead to longer unit life span

9.6 amps (20 Amp Max fuse)

EverCheck™ alert system

CycleSaver™ design

Integrated ultrasonic bin control

Simple, one-hour cleaning and assisted cleaning process with CleanAssist

Heat Rejection: 17100 BTU/hr

Three Years: Parts & Labor warranty on entire machine

Five Years: Parts & Labor warranty on evaporator

Specifications

Product Details

Electrical Specs	Single phase, 208-230v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included, Amperage: 9.6, Max Fuse/HACR Breaker: 20 A
Utility Consumption	4 kWh per 100 lbs @ 90/70, 20 gal of Potable Water per 100 lbs @ 90/70
Operating Limits	Ambient Temp Range: 45 – 100°F, Water Temp Range: 45 – 90°F, Water Pressure: 10 – 113psig, Voltage Range: 187 – 253V, Heat Rejection: 17100 BTU/hr, Refrigerant Charge: R-404A, (1 lbs. 10.5 oz
Plumbing Specs	1/2″ FPT Inlet, Minimum 3/8″ Nominal ID Copper Water Tubing or Equivalent, 3/8″ FPT Outlet, Minimum 3/8″ Nominal ID Hard Pipe or Equivalent, Minimum 3/8″ Nominal ID Copper Water Tubing or Equ
Shipping Weight	280
