Name: Crescent Cuber Icemaker, Remote-cooled
Brand: Hoshizaki
SKU: KM1601MRJ
Availability: BackOrder

Crescent Cuber Icemaker, Remote-cooled

Model : #KM1601MRJ

Crescent Cuber Icemaker, Remote-cooled

Model: KM1601MRJ

Crescent Cuber Icemaker, Remote-cooled

Model: KM1601MRJ

Color : Stainless Steel

Key Features

Up to 1594 lbs of ice produced per 24 hours
Mount 2 units side-by-side for 2x the ice production
Produces crescent shaped ice cubes
Durable stainless steel exterior
Compatible bins & dispensers, sold separately: B-250, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650
R-404A refrigerant ( / )
Ambient temperature range: 45 – 100°F
Water temperature range: 45 – 90°F

Description

The KM-1601MRJ is capable of producing approximately 1594 lbs of crescent cubed ice, Mount 2 units side-by-side for 2x the ice production in the same floor space! Our efficient double-sided KMEdge stainless steel evaporators create our unique crescent shaped ice cubes. It is the purest and hardest ice on the market and is a perfect fit for a wide range of applications. This Remote-cooled with URC-22F icemaker features a CycleSaver™ design and includes the EverCheck™ alert system making the unit energy efficient and simple to maintain. The KM-1601MRJ requires a Single phase, 208-230v/60/1, 4 wire, including ground. Must be hardwired at site, no cord/plug included. If neutral is not available transformer kit (HS-5030) is required electrical connection that is hard-wired at the installation site. Remote condenser sold separately. Compatible bins & dispensers, sold separately: B-250, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650. Please consult the Specification Sheet for additional details. KM-1601MRJZ.

Documents

Specification Sheet

View | Download

PDF, 1.02 MB

Service Manual

View | Download

PDF, 3.98 MB

Warranty Statement

View | Download

PDF, 999.31 KB

Available from Slyman Bros, serving customers throughout Missouri.

Features

Specifications

Features

Up to 1594 lbs of ice produced per 24 hours

Mount 2 units side-by-side for 2x the ice production

Produces crescent shaped ice cubes

Durable stainless steel exterior

Compatible bins & dispensers, sold separately: B-250, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650

R-404A refrigerant ( / )

Ambient temperature range: 45 – 100°F

Water temperature range: 45 – 90°F

Water pressure: 10 – 113psig

Voltage range: 187 – 253V

15.9 amps (20 Amp Max fuse)

4.35 kwh/100 lbs.@ 90/70

Single phase, 208-230v/60/1, 4 wire, including ground. Must be hardwired at site, no cord/plug included. If neutral is not available transformer kit (HS-5030) is required

Clean ice and easy maintenance lead to longer unit life span

Five Years: Parts & Labor warranty on evaporator.

Dimensions: 30″ W x 27-3/8″ D x 41- 5/8 ” H

EverCheck™ alert system

CycleSaver™ design

Heat Rejection:24300 BTU/hr

Three Years: Parts & Labor warranty on entire machine.

Specifications

Product Details

Utility Consumption	4.35 kWh per 100 lbs @ 90/70, 18 gal of Potable Water per 100 lbs @ 90/70
Electrical Specs	Single phase, 208-230v/60/1, 4 wire, including ground. Must be hardwired at site, no cord/plug included. If neutral is not available transformer kit (HS-5030) is required, Amperage: 15.9, Max
Operating Limits	Ambient Temp Range: 45 – 100°F, Water Temp Range: 45 – 90°F, Water Pressure: 10 – 113psig, Voltage Range: 187 – 253V, Heat Rejection: 24300 BTU/hr, Refrigerant Charge: R-404A, ( / )
Plumbing Specs	1/2″ FPT Inlet, Minimum 3/8″ Nominal ID Copper Water Tubing or Equivalent, 3/4″ FPT Outlet, Minimum 3/4″ Nominal ID Drain Hard Pipe or Equivalent
Shipping Weight	320

Dimensions & Weight
