Name: Crescent® Cuber Icemaker, Water-cooled, 3 Phase
Brand: Hoshizaki
SKU: KM2600SWJ3
Availability: BackOrder

Crescent® Cuber Icemaker, Water-cooled, 3 Phase

Model : #KM2600SWJ3

Crescent® Cuber Icemaker, Water-cooled, 3 Phase

Model: KM2600SWJ3

Crescent® Cuber Icemaker, Water-cooled, 3 Phase

Model: KM2600SWJ3

Color : Stainless Steel

Key Features

Up to 2482 lbs of ice produced per 24 hours
Durable stainless steel exterior
Stack 2 units for 2x the ice production
Produces crescent shaped ice cubes
R-404A refrigerant (3 lbs. 7.7 oz. / 1580 g)
Compatible bins & dispensers, sold separately: B-800, B-900, B-1150, B-1300, B-1500, B-1650
12.8 amps (30 Amp Max fuse)
3.6 kwh/100 lbs.@ 90/70

Description

The KM-2600SWJ3 is capable of producing approximately 2482 lbs of crescent cubed ice, Stack 2 units for 2x the ice production in the same floor space! Our efficient double-sided KMEdge™ stainless steel evaporators create our unique crescent shaped ice cubes. It is the purest and hardest ice on the market and is a perfect fit for a wide range of applications. This Water-cooled, Stackable, 3 Phase icemaker features a CycleSaver™ design and includes the EverCheck™ alert system making the unit energy efficient and simple to maintain. The KM-2600SWJ3 requires a Three phase, 208-230v/60/3 electrical connection that is hard-wired at the installation site. Compatible bins & dispensers, sold separately: B-800, B-900, B-1150, B-1300, B-1500, B-1650. Please consult the Specification Sheet for additional details.

Documents

Service Manual

View | Download

PDF, 4.40 MB

Instruction Manual

View | Download

PDF, 3.92 MB

Parts Manual

View | Download

PDF, 2.73 MB

Warranty Statement

View | Download

PDF, 999.31 KB

Specification Sheet

View | Download

PDF, 1.58 MB

Available from Slyman Bros, serving customers throughout Missouri.

Features

Specifications

Features

Up to 2482 lbs of ice produced per 24 hours

Durable stainless steel exterior

Stack 2 units for 2x the ice production

Produces crescent shaped ice cubes

R-404A refrigerant (3 lbs. 7.7 oz. / 1580 g)

Compatible bins & dispensers, sold separately: B-800, B-900, B-1150, B-1300, B-1500, B-1650

12.8 amps (30 Amp Max fuse)

3.6 kwh/100 lbs.@ 90/70

Clean ice and easy maintenance lead to longer unit life span

EverCheck™ alert system

CycleSaver™ design

Three phase, 208-230v/60/3

Integrated ultrasonic bin control

Simple, one-hour cleaning and assisted cleaning process with CleanAssist

Heat Rejection: 31600 BTU/hr

Three Years: Parts & Labor warranty on entire machine

Five Years: Parts & Labor warranty on evaporator

Specifications

Product Details

Electrical Specs	Three phase, 208-230v/60/3 , Amperage: 12.8, Max Fuse/HACR Breaker: 30 A
Utility Consumption	3.6 kWh per 100 lbs @ 90/70, 16 gal of Potable Water per 100 lbs @ 90/70
Plumbing Specs	1/2″ FPT Inlet, Minimum 3/8″ Nominal ID Copper Water Tubing or Equivalent, 3/8″ FPT Outlet, Minimum 3/8″ Nominal ID Hard Pipe or Equivalent, Minimum 3/8″ Nominal ID Copper Water Tubing or Equ
Shipping Weight	425
Operating Limits	Ambient Temp Range: 45 – 100°F, Water Temp Range: 45 – 90°F, Water Pressure: 10 – 113psig, Voltage Range: 187 – 253V, Heat Rejection: 31600 BTU/hr, Refrigerant Charge: R-404A, (3 lbs. 7.7 oz.

Dimensions & Weight
